Description

LCD Remote Water Meter Reader VL-9S

This remote LCD reader can be used specifically with REED SWITCH type input. Tapping on the gold target displays the current reading. The meter reading displays for 10 seconds. This display can be used ONLY with the reed switch/dry contact register output meters.

Wire is not included. If your encoder does not have a wire lead, you will need to add 2 conductor cable.

MODEL VL-9S FEATURES:

• Environmentally sealed
• Connects to a reed switch (dry contact) output register (2 wires)
• Large easy to read display
• “TAP” switch to display current meter reading.
• 5 year limited manufacturer warranty
• Solution for confined space meters
• Convenient cost effective solution to inaccessible meters, i.e., Shopping Malls, etc.

PHYSICALS:

• 4.6″ X 4.3″ X 2″ thick (11.7cm X 10.9cm X 5.1cm thick)
• Operating Temperature: -30 to 80°C (-22 to 176°F)
• Weight: 9oz (254g)

METER CONNECTIVITY:

• Reed switch (dry contact) meter output
• See other listings for the VL-9 version for encoder registers
• If your meter has 3 wire output, you likely need the plain VL-9 encoder version

VL9S, VL-9S, VL9-S
